ALS LuminaFlex 400

The ALS LuminaFlex 400 LED BSW is a versatile 3-in-1 moving head light with beam, spot, and wash capabilities. Here are its key specifications:

Light Source & Power

Source: 400W white LED (7500K color temperature)

Power Consumption: 550W

Voltage: AC100~240V, 50/60Hz

LED Life: >20,000 hours

Movement

Pan: 540° (16-bit resolution, auto repositioning)

Tilt: 270° (16-bit resolution, fast, quiet, smooth motion)

Optics

Zoom Range: 3°–45° linear zoom

Focus: Motorized

Color & Gobos

Color Wheel: 1 wheel with 8 colors + white (interchangeable, indexable, bidirectional rainbow effect)

Fixed Gobo Wheel: 9 gobos + open (with gobo shaking effect)

Rotating Gobo Wheel: 7 interchangeable gobos + open (indexable with gobo shaking)

Effects

Prism: 5-facet rotating prism (motorized positioning)

Dimming: 0–100% linear dimming

Strobe & Frost: Various strobe effects and frost available

Control

DMX Channels: 19/25 channels

Protocols: DMX, ArtNET (optional), RDM compatible

Features: Remote fixture reset, sound control by DMX, input signal isolation

Display

2.8-inch LCD (English/Chinese menu)

Auto lock and display flip, pan/tilt reverse

Physical Specs

Dimensions: 460 x 340 x 690 mm

Net Weight: 16.5 kg

Gross Weight: 18.5 kg
